IPLEX - Industrial Videoscope
A Videoscope with a Clear Vision
The IPLEX RX and IPLEX RT provide unsurpassed image quality yet are user‐friendly, and boast a portable design.
The videoscopes are ideal for inspectors who require uncompromised and precise inspections.
Exceptional Image Quality
•Our brightest and sharpest image quality
•Recorded images and movies in high quality
•Expanded image adjustment capability for optimum inspections
•Large 6.5 in. monitor
Operation with Ease
•Compact and portable casing
•Multi‐positioning design for comfortable inspection
for any application
•Excellent scope maneuverability with TrueFeelTM and
Tapered FlexTM technologies
•Intuitive and quick operation
Rugged and Durable
•Heavy‐duty system compliant with MIL‐STD and IP55
•High‐durability insertion tube withstanding crush and abrasion
•100 °C / 212 °F capable insertion tube with temperature alert
Advanced Functionality
•Stereo Measurement for objective inspections
•PDF display function enabling efficient inspection work
•InHelp software to streamline all stepsfrom inspection to report generation
Our Best Image Quality
The IPLEX RX and RT feature the best image quality of our videoscopes. Our unique PulsarPicTM image processor reduces noise and sharpens images, resulting in the exceptionally high resolution image.The IPLEX RX and RT faithfully and brightly reproduce very small defects, and the sharp and clear images enable accurate and reliable inspections.
2X Brighter Illumination System
The IPLEX RX and RT feature a new LED illumination system that is approximately twice as bright as conventional videoscopes, while dynamically adjusting light output to reduce halation when metal or reflective surfaces are inspected.The PulsarPicTM image processor interacts intelligently with our illumination system to deliver an optimized amount of light and gain enhancement to provide images that are very clear and sharply defined.Turbine bladesBearing of wind gearboxCombustion chamber
Diverse Applications
Turbine blades
Bearing of wind gearbox
Combustion chamber
Welding
Still Images and Movies as Crisp as Live Images
The IPLEX RX and RT can record inspected images toa removable USB flash drive as JPEG still images and MPEG–4 movies.The improved image quality of recorded images and movies enables accurate image diagnosis not only in the field but also at the office with the use of our free image management software, InHelp viewer.
Large Monitor Providing Easy Yet Accurate Inspections
The compact IPLEX RX and RT are equipped with a 6.5 in. monitor. The large monitor displays small defects clearly from a comfortable distance for inspectors foreasy identification.
Comparison of image sizes
Optimized Image Gradation
The IPLEX RX features our unique image processing
capability, WiDERTM, which brings out the darkest areas
of an image without washing out the details of the brighter
regions. The innovative technology provides optimum
inspections of large areas or even highly reflective areas.
In addition, the IPLEX RX is equipped with sharpness
and color adjustment functions to create optimal images
depending on objects and applications.
Sharpness: Level ‐1/ Color: Standard/ Normal gain setting
Sharpness: Level 2/ Color: Vivid/ WiDERTM gain setting
Compact and Portable Design
The IPLEX RX and RT weigh just 2.9 kg/ 6.4 lb including the two‐hour operating Li‐ion battery. The compact and portable design allows you not only to easily ship or transport the IPLEX RX and RT to inspection sites but to smoothly carry them to difficult-to-access locations.
The IPLEX RX carried up a ladder with a shoulder strap
The compact and neat design is easy to carry with one hand
The same inspected image is shared between two operators with an external display connected to the IPLEX RX for remote observation
The IPLEX RX sits on a surface using its pivoting handle to angle the image just right
Comfortable Inspections in Optimal Styles
The versatile design of the IPLEX RX and RT offers comfortable use to almost anyone. The pivoting handle
of the monitor can change into a stand during inspections, and allows you to place the videoscope wherever you want to optimize viewing distance and angles. The
video output capability of the IPLEX RX and RT enables inspections in a group or from remote locations by connecting the external monitor. Furthermore, the IPLEX RX and RT can be used while being carried with a shoulder belt or connected onto a tripod.
Smooth and Accurate Approach
to a Target
The innovative articulation technologies equipped on the IPLEX RX and RT allow for smooth and accurate approaches to the most demanding inspection paths.
The improved TrueFeelTM articulation controller features precise and quick scope tip articulation by just light‐touch operation, achieving smooth navigation through intricate paths.
The insertion tube is designed with the unique
Tapered FlexTM to optimize both the scope stiffness
and flexibility for excellent scope maneuverability.
TrueFeel articulation providing a precise and controlled bend at the distal end
Quick and Easy Operation
The most common operations such as scope articulation, image adjustment and recording can be easily activated by pressing dedicated Quick Access keys on the lightweight handset. The menu setting of the IPLEX RX and RT is simplified for easy and quick operation.
User‐friendly Menu Icons
All menus of the IPLEX RX and RT are displayed with easy‐to‐understand icons. An inspector can intuitively recognize the menus and efficiently operate the desired feature or setting.
The handheld controller boasting Quick Access keys capable of over 14 actions in a single touch
The IPLEX RX intuitive menu shows the options for image overlay
Robust Body
The IPLEX RX and RT pass the impact tests including vibration and drop from a height of 1.2 m/ 3.9 ft.
The tough system compliant with Military Standards withstands rough treatment and ensures reliable operation in difficult environments.
Operable in All Weather
The IPLEX RX and RT comply with internationally recognized Military Standards (MIL‐STD‐810F/G and MIL-STD‐461F)* as well as IP55, passing a range of severe environmental tests, such as blowing rain/dust, high humidity, and icing rain. In addition, the daylight view monitor featuring low‐reflection displays clear images even under bright sunlight.
High‐durability Insertion Tube
Operators are often required to inspect objects inside narrow paths with rough or sharp surfaces. The insertion tube of the IPLEX RX and RT has a crush and abrasion‐proof design and is covered with a tough, special processed tungsten braid.
In addition, the IPLEX RX insertion tube features high temperature resistant up to 100 °C/ 212 °F. A high
temperature sensor beeps and display visual warning to prevent overheating.
Special processed tungsten braid
Stereo Measurement for Reliable Inspection
Our advanced Stereo Measurement technology offers
outstanding reliability and accuracy for your inspections.
By capturing image information through two parallax
lenses, the IPLEX RX permits accurate measurement of
almost any object from any angle.
Additionally, our unique Spot‐RangingTM feature on the
IPLEX RX, the industry’s only real‐time tip‐to‐target
distance measurement tool, navigates the scope tip to
the optimum distance from a target for the most precise
measurement on the first try.
Depth measurement accomplished with the IPLEX RX Stereo Measurement
Principle of Stereo Measurement technology
InHelp Inspection Assist Software
InHelp, the inspection data management and reporting
software, streamlines many aspects of remote visual
inspections with the IPLEX RX and RT. The software
greatly improves work efficiency and simplifies inspections
by organizing stored images on the IPLEX RX and RT,
generating detailed inspection reports* on a PC with
simple click operation.
Instruction Manual Display
IPLEX RX has a function to display PDF document.
Instead of alternately facing printed inspection manuals
and inspected images, you can see both of them on the
IPLEX RX monitor at once. This unique capability improves
your inspection speed and efficiency.
Optional report generation can be added to compliment the InHelp software
Comparison display between an inspected image and PDF document
